V.92 Desktop Business Modem



Benefits

Increased upload speeds
Quicker connect times
Modem-on-hold
V.34/33.6K Super G3 Fax
Global approvals

The MultiModemZBA V.92 business modem supports remote configuration, callback security, as well as dial-up and 2-wire leased line connections making it the modem of choice for business applications. With V.92, this modem provides an increase in upload speeds and quicker connect times than traditional V.90 modems. It offers V.34/33.6K fax and Error Correction Mode, that reduces fax transmission time by more than half when compared to traditional fax modems. In addition, it is approved for use in many countries around the world. This means one model can ship virtually anywhere.


Features

V.92/56K download speeds and 48K upload speeds when connecting with V.92 servers
Quick connect feature can cut the time required for a dial-up modem to "handshake"
  to an ISP or other connection in half
Modem-on-hold feature allows the modem to work in conjunction with call waiting provided
  by phone company
V.44 compression improves data throughput rates
Class 1.0 and Class 2.1 faxing at speeds to V.34/33.6K bps (Super G3)
Error Correction Mode (ECM) provides fast and reliable fax transmissions
Windows 95/98/Me/2000 Plug-and-Play operation
U.S. Caller ID reporting
Remote configuration for centralized setup and control
Callback Security for network security and reduced telephone toll charges
Voice support for voice mail and full duplex speakerphone (voice models only)
Global approvals in many countries for worldwide use
Country localization kits available with power cords, phone cords and telco adapters
Flash memory for easy updates


Highlights

Increased Upload Speeds. With the V.92 MultiModemZBA, you can achieve an upload speed of 48K bps (30% increase over V.90 modems). This higher upstream speed reduces data transfer time for large e-mails with attachments and for ftp site uploads, as well as improves operation for interactive applications.

Quick Connect. The V.92 MultiModemZBA quick connect feature reduces the dial-up connection time by as much as 50% for a modem to "handshake" to an ISP or other connection.

Modem-on-Hold. The modem-on-hold feature allows the V.92 MultiModemZBA to work in conjunction with call waiting provided by the phone company. Users can answer a new phone call for up to 16 minutes without dropping the modem connection. Users are then able to resume surfing the Internet after they terminate the voice call.

V.44 Compression. V.44 is a new data compression standard that will improve the current V.42bis data compression anywhere from 20 to 60 percent, up to as much as 200 percent for certain types of highly compressible data. The compression technique, used by the V.92 MultiModemZBA, enables data throughput rates of higher than 300K bps - much faster than today¡¦s typical rates of 150 - 200K bps. For users, it means that your Web browsing will be much faster.

Enhanced Fax Features. The V.92 MultiModemZBA supports V.34 fax and Error Correction Mode providing significant performance and reliability enhancements over previous fax standards. V.34 sends and receives faxes at 33.6K, more than double the speed of the V.17/14.4K fax standard. Error Correction Mode adds reliablility while increasing performance of fax transmissions. Together these enhancements increase the performance of the V.92 MultiModemZBA to levels previously only found in more expensive dedicated fax boards and machines.

Global Approvals. With the V.92 MultiModemZBA, you need just one modem for worldwide use. This model has approvals in many countries so you can ship one SKU (stock unit) virtually anywhere in the world. Localization kits are available for country-specific power cords, phone cords and telco adapters.


Specifications

Models
MT5634ZBA-V92-GB - V.92 Data/Fax World Modem
MT5656ZBA-V-V92-GB - V.92 Voice/Data/Fax World Modem
Rates
Data: V.92/56K downloads and 48K upload speeds from V.92 servers; V.90/56K downloads from V.90/K56flex servers; 33.6K bps transfers with other servers
Fax: 33.6K/14.4K bps
Standards
Data: V.92, V.90, enhanced V.34 & below
Error Correction: V.42
Data Compression: V.44, MNP®Class 5; V.42bis
Fax: V.34, Class 2.1 and Class 1.0, V.17, Group 3, Class 1 & Class 2, Error Correction Mode (ECM)
Voice: AT+V/TAM voice command set
Video: V.80
Connectors
2 RJ-11s & DB25
Operation
Async/230.4K bps
Dial-up or 2-wire leased line
Operating Systems Support
Windows 3.1x, Windows 95/98/Me/2000/XP, Windows NT, Linux, SCO OpenServer & others
Physical Description & Operating Environment
4.3" w x 1.0" h x 5.7" d; 8 oz
(10.9 cm x 2.5 cm x 14.5 cm; 227g)
32-120°F (0-50°C); 20-90% noncondensing
Approvals
FCC Parts 15B & 68; UL 1950; CE Mark
