 Network
Video Solution
AM2191
Audio Module
Sight, Speech and
Sound - over IP
Used
together with the network
cameras, the AM2191 Audio Module enhances the visual communication
by adding audio capability. The combined products offer communication
via microphones and loudspeakers along with the live images over
networks and the Internet.
Suitable
for use in applications like Web attraction and remote monitoring,
the AM2191 Audio Module allows users to take part, manage and
experience remote activities, office meetings and tourist locations.
No need for additional software - Internet Explorer is all that's
needed!
| Features |
 |
Enhances
video communication with audio capability |
|
Easy
to install and use ¡X no extra software required |
|
Communications
over networks and the Internet |
|
Easy
access to real time audio/video |
 |
Client PC with a Pentium II 266 Mhz, 128 Mb of RAM full duplex
sound-card |
| |
(for full duplex mode) |
|
AM2191 Audio Module can be used with: Windows 98, ME, 2000
and NT (SP4) |
|
Internet
Explorer (4.x, 5.x) is required |
| Operating
Environment |
|
Temp:
5-50°C (40-122°F) |
|
Humidity:
8-80 % RHG, relative humidity |
| Dimensions
and Weight |
|
Height:
27 mm (1.1") |
|
Width:
112 mm (4.4") |
|
Length:
110 mm (4.3") |
|
Weight: 320 g (0.7 lb) (excl. power supply) |
| Approvals |
|
|
EMC: This
equipment complies with the requirements in Part 15 subpart
B of FCC Rules |
| |
for
Class A computing
device |
|
CE:
EN55022 Class B, EN55024 |
|
FCC:
Class A |
|
Safety:
EN60950, UL, CSA |
|
Accessories Included |
|
Null
modem cable for connection to the camera |
|
Power
cord extension cable |
|
Power
supply: 12V AC, 9.6 VA |
|
I/O connector |
| Connections
and Controls (Rear) |
|
Socket
for external microphone -optional (In), |
 |
| |
1-50mVpp.
PC type |
|
Volume
level control (Volume In) |
|
Built-in
microphone (Mic) |
|
Output
volume level control (Volume Out) |
|
Speaker
socket (Out), Unbalanced, |
| |
0.05-1.0Vpp |
|
|
Microphone
switch (Int-Ext) |
|
|
Volume
indicators (Level In/Level Out) |
|
Auxillary
connector (Terminal Block Indicator) |
| |
Line
In: Balanced 0.05-1Vpp. Connect source ground to pin 2 and
source signal to pin 1 |
| |
if
the source is unbalanced |
| |
Line
Out: Unbalanced, 0.05-1.0Vpp |
| Connections
and Controls (Front) |
 |
|
Power connector (PS-D), |
| |
Serial Port Connector, Power and Activity indicators |
|
9-pin
D-SUB serial connector: RS-232 (COM) |
|
Power
and Activity indicators |
| |
|
| |
|
|
|
|
|
|
