Network Video Solution

802.11b Wireless Access Point
Make your move from wired to wireless surveillance!

Unleash your video surveillance cameras with 802.11b Access Points. For wireless network video installations that can be viewed from anywhere, these handy WLAN devices plug directly to Ethernet Hubs/switches to offer a flexible solution for developing video applications.

Use them together with 802.11b Device Points and integrate network video products into new and existing WLAN infrastructures. So now... you can liberate whatever network camera or video server from its cabling to the network!

	Features
		Offers wireless communication
		over distances of up to 300ft/100m
		Supports 128-bit WEP encryption
		for reduced risk of unauthorized video access
		Compatible with all 802.11b
		compliant devices
		Dual antenna design ensures
		optimal RF performance

Technical Specifications - 802.11b Wireless Access Point
General
	802.11b Wireless Access Point
	1, 2, 5.5, 11 Mbit/s data rate
Features
	Wireless Auto Speed Option
	Web Interface Configuration
	Windows-based Firmware Upgrade Tool
Management
	Windows-Based Utility
	Web-Based Management
Security
	WEP encryption 64bits and 128bits
	MAC address filter
Operating Environment
	Operating Temperature: -10 - 55°C (14 - 131°F)
	5 ~ 95% (Non-condensing)
	Requires proper environmental housing for outdoor use

External Indicators
	Power
	Ethernet Activity
	Wireless Activity
Hardware

	Atmel AT76C502A CPU
	512Kb Flash memory
	256Kb RAM
	External and internal antenna

Connections

	RJ45 twisted pair direct network connection for 10baseT Ethernet
	External power supply connector 5V DC, 2 A
Dimensions and Weight
	108.2(L) x 80.9(W) x 29.8(H) mm
	4.3(L) x 3.2(W) x 1.2(H) Inches
	75g
Certificates
	FCC for N. America, TELEC for Japan and ETSI for most of Europe
Supported Protocols
	TCP/IP
Power Supply
	5V/2A DC
	Power consumption max 800mA (5V)
Operating Frequency
	America/FCC: 2.412~2.462 GHz (11 channels)
	Europe CE/ETSI: 2.412~2.472 GHz (13 channels)
	Japan: 2.412~2.484 GHz (14 channels)
	France: 2.457~2.472 GHz (4 channels)
	Output Power: 20dBm (Maximum)
Approvals
	CE/LVD	EN60950:1992+A1+A2+A3+A4+A11
	CE/EMC	EN 301 489-17 V1.1.1: 09-2000
		EN 301 489-1 V1.3.1: 09-2001
		EN 300 328-1 V1.3.1: 08-2001
		EN 301 328-2 V1.2.1: 12-2001
	FCC Part 15
